Product Introduction:

The electric multi-leaf butterfly valve is a type of louvered ventilation regulating valve.

The valve body is available in both circular and rectangular structures.

Driven by an electric actuator and a linkage mechanism, it causes multiple blades to rotate synchronously (0°~90°),continuously changing the airflow area of the duct to achieve balanced regulation and on/off control of air volume and pressure.

It is mainly used in low-pressure, high-flow gas pipelines, suitable for media such as dusty hot air, flue gas, exhaust gas, and air.

It is a core piece of equipment in dust removal systems, kiln flues, desulfurization and denitrification systems, HVAC systems, and automated ventilation systems in metallurgical mines.

Structural Components:

Valve Body Frame: Welded steel plate (Q235 / Stainless Steel), rectangular / circular flange structure.

Multiple Blades: Louvered valve plate, synchronous linkage drive system.

Valve Shaft, self-lubricating bearing, smooth rotation and not prone to jamming

Electric Actuator (On/Off Type / Intelligent Adjustment Type).

Optional: Sealing strip, high-temperature resistant coating, explosion-proof structure.

Application Industries:

Environmental dust removal, waste gas treatment, waste incineration flue gas ducts.

Cement and building material kiln air supply and exhaust systems.

Metallurgical blast furnace and sintering machine flue gas ducts.

Power plant desulfurization, denitrification, and induced draft ducts.

Mine ventilation, large factory HVAC ducts.

Chemical waste gas and coal gas transmission and regulation pipelines.

Technical Parameters

Dimensions:

Round: DN200～DN6000.

Rectangular: Width × Height (customizable).

Nominal Pressure: PN0.1MPa, PN0.25MPa, PN0.6MPa.

Applicable Media: Air, hot air, flue gas, dusty gas, exhaust gas, low-temperature coal gas.

Operating Temperature:

Q235 Carbon Steel: -20℃～350℃.

304 Stainless Steel: -40℃～600℃.

High Temperature Resistant Stainless Steel: Maximum 850℃.

Valve Body/Blade Material: Q235B Carbon Steel, 304, 316L, 310S.

Sealing Type:

Ordinary No-Seal Type: General ventilation and regulation, leakage rate ≤3%.

Soft-Seal Low-Leakage Type: Normal temperature clean air, leakage rate ≤1%.

Metal Contact Seal: High temperature flue gas conditions (rubber not allowed).

Permissible Air Velocity: ≤25m/s.

All valves are equipped with professional export protective packaging.

With protective caps on the sealing surfaces, rust-proof treatment, and shock-absorbing material filling to ensure intact transport; the loading is secure and safe.

We can also customize packaging according to customer requirements.

Regarding transportation methods, we can provide appropriate transportation options based on the cargo requirements and the customer's timeliness requirements.

Common transportation methods include: sea freight, air freight, land freight, and express delivery.
