Product Introduction:
The electric globe valve consists of globe valve body and electric actuator.
Driven by electric motor, the stem and disc move up and down to realize remote shut-off and flow regulation.
Medium flows from below disc upward.Multiple body materials including cast iron, WCB carbon steel, 304 / 316 stainless steel for different working conditions.
It can connect with PLC & DCS system to realize automatic control, widely used in heating, chemical, water treatment and oil pipelines.
Main Features
Forced metal hard sealing, reliable tight shut-off.
Optional actuator: On-off type / Modulating type (4-20mA) / Explosion-proof type.
Manual override handwheel for emergency operation during power failure.
IP65 protection standard; limit switch & position feedback signal available.
Bolted bonnet design for convenient maintenance.
Specifications:
Operation type:Electric
Size: DN50-DN1200
Pressure: PN10/16/ Class125/150,JIS6K/10K
Face to Face Standard: API609,BS5155,DIN3202,ISO5752
Flange Standard:DIN,BS,ISO,ANSI,AS,JIS
Materials:
Body : WCB
Disc: WCB
Packing:PTFE + Graphite
Gasket: Graphite
Stem : Stainless Steel
Characteristic:
Applicable Medium: Water, Oil, Gas
Applicable Temperature:-29~425℃
All valves are equipped with professional export protective packaging.
With protective caps on the sealing surfaces, rust-proof treatment, and shock-absorbing material filling to ensure intact transport; the loading is secure and safe.
We can also customize packaging according to customer requirements.
Regarding transportation methods, we can provide appropriate transportation options based on the cargo requirements and the customer's timeliness requirements.
Common transportation methods include: sea freight, air freight, land freight, and express delivery.
