Product Introduction:
Two-piece ball valve is the most economical floating ball valve composed of two body halves fastened by bolts, available in threaded, flanged and butt weld connection.
It realizes pipeline on-off by 90-degree rotation, equipped with handle, pneumatic or electric actuator.
Material: SS304, SS316L, Carbon Steel WCB, Cast Iron
Seat Option: PTFE soft seat for bubble tight shut-off, metal hard seat for high temperature service
Pressure & Size: PN16/PN25, Class150/300, DN8-DN200
Advantages:
Cost-effective structure for general industrial isolation;
Full bore design for low flow resistance;
Bidirectional sealing, easy installation;
Compact layout for narrow pipeline space.
Application: Water supply, natural gas pipeline, HVAC system, air compressor, general petrochemical pipeline, fire protection system.
Core Technical Parameters:
Nominal diameter: DN8 to DN200..
Nominal pressure: Mainly PN16 and PN25, a few reaching PN40; American standard Class150, Class300
Thread/Fastener standard: National standard GB, American standard ANSI NPT, British standard BSP.
Leakage level: Soft seal VI level (bubble-free zero leakage), metal hard seal IV level.
Air source (pneumatic model): 0.4–0.6MPa compressed air.
All valves are equipped with professional export protective packaging.
With protective caps on the sealing surfaces, rust-proof treatment, and shock-absorbing material filling to ensure intact transport; the loading is secure and safe.
We can also customize packaging according to customer requirements.
Regarding transportation methods, we can provide appropriate transportation options based on the cargo requirements and the customer's timeliness requirements.
Common transportation methods include: sea freight, air freight, land freight, and express delivery.
